Maxiflame MX140/2CCB Mini Boiler/Thermoproduct Interface Module

Maxiflame MX140/2CCB Mini Boiler/Thermoproduct Interface Module



The MX140/2CCB Mini from Maxiflame is a module designed to allow multiple heat generators (boiler, biomass thermoproduct and heat pump) to work together within the same domestic system.

Simply put: it is the “hydraulic brain” that allows the various heating systems not to conflict with each other , working in a coordinated, efficient and safe way.

What is it for?

When you have multiple heat sources in your home (e.g. fireplace + boiler + heat pump), without a module like this:

• the circuits influence each other
• inefficiencies are created
• the system becomes difficult to manage

The MX140/2CCB Mini:

• separates the circuits hydraulically
• manages which generator should work
• optimizes heat exchange

result: stable, efficient and automatic system

How it works

• the system starts normally with the boiler
• when the thermoproduct (e.g. thermo fireplace) reaches the temperature:
  • the module activates the circulators
  • transfers heat to the system via the exchanger
  • automatically turns off the boiler

all this happens without manual intervention.

The module integrates a 3-circuit plate exchanger with 40 plates in AISI 316 L stainless steel , which:

• completely separates the circuits
• allows heat to pass without mixing the fluids
• improves system performance and safety

Where to use it

Ideal for:

• homes with a thermo-fireplace or hydro stove + boiler
• systems with heat pump and buffer tank
• generator renovations or replacements

perfect for modern systems and hybrid systems.

Main technical data

• Power: 35 kW
• Exchanger: 40 plates – 3 circuits – AISI 316 L
• Circulator: Wilo PARA 15/8 SC
• Connections: 1”
• Dimensions: 735 x 600 x 125 mm
• Cover box included

Differences compared to other Maxiflame modules

Compared to MX115 / MX135 modules

• MX140/2CCB Mini is more advanced and complete
• manages 3 circuits (not 2)
• designed for complex hybrid systems (even with heat pump)
• greater control and stability of the system

Compared to MX135/2 (with ACS)

• MX135/2 produces domestic hot water (DHW)
• MX140/2CCB Mini instead is dedicated only to heating
• but offers more advanced management and compatibility with more generators

Compared to the MX140/2CCB version (not Mini)

• the Mini version is more compact
• can have simplified configuration (e.g. circulator management)
• ideal for domestic installations with limited spaces



NB: FOR FURTHER TECHNICAL DETAILS WE RECOMMEND VIEWING THE ATTACHED TECHNICAL DATA SHEET.



WARRANTY

The warranty is the official Maxiflame one and lasts 2 years.
